Elero Tubular Motor Type 15/18 W NMA
ITEM IS SOLD ONLY TO TRADERS!
323320002
- Tubular motors with manual override for gates
- Wired tubular drive
- without radio
- Particularly robust and versatile
- Interchangeable couplings (adapters) possible for tubes from Ø 98 x 2.0 mm to 168 x 4.0 mm or SW 114 (octagonal)
- Long service life
- Quiet drive operation thanks to optimal gearing
- The mounting plates of the Type 15 W... drives must be mounted at right angles to the mounting surface
- In case of unevenness, the wall anchor pocket item no. 231000001 must be used
- Shaft diameter from (mm): 98
- Degree of protection (IP): 44
- Limit switch range (revolutions): 36
- Gate cycles per hour h-1 *: 6
- Gear ratio NMA to winding shaft: 243 : 1
- Length: 640 mm
- Weight (kg): 12.1
- Rated torque (Nm): 180
- Rated speed (rpm): 12
- Rated voltage (V): 1 ~ 230
- Rated current (A): 3.6
- Rated input (W): 780
- Operating time (min S2): 6
- Material: Steel and plastic
- Colour: Grey
Scope of delivery: 1 motor with connection cable
